Kipp & Zonen SMP12 Pyranometer 太陽光幅照度計
產品編號：
The new SMP12 is fast response spectrally flat Class A pyranometer that combines solid-state dome heating, with no moving parts, and best-in-class surge protection to maximize accuracy and minimize maintenance. 新型 SMP12 快速反應的 A 級日照輻射計光譜平坦，全天候測量太陽日照輻射，採用固態穹頂加熱技術，沒有任何移動式部件，優異保護功能，大幅提高精準度並減少日常維護量。
The SMP12 combines proven sensor and diffuser technology from the RaZON+ PH1 and PR1 radiometers with an enhanced version of the Smart interface and the low maintenance of the SMP10. 結合 RaZON+ PH1 和 PR1 輻射計成熟的感測器和擴散器技術，並配備強化版智慧介面，同時保留 SMP10 的低維護量特色。
The SMP12 has an internal drying cartridge that will last for at least 10 years if the housing is unopened. This reduces maintenance significantly. Due to the SMP12's superior non-stability, the instrument needs to be recalibrated every 5-years from the date of installation to remain within its performance parameters. To be compliant with IEC61724-1 Class A system requirements, recalibration is every 2-years from date of installation. SMP12 內建乾燥盒，在未打開外殼的情況下，乾燥盒的使用年限可達 10 年。此明顯降低日常維護量。為保持其性能參數，自安裝之日起需要每 5 年進行重新校正。為符合 IEC61724-1 A 級系統要求，建議自安裝日起每 2 年進行一次重新校正。
The SMP12 feature set includes:
*Solid-state dome heating for dew and frost prevention. 固態穹頂加熱，防止露水和霜凍
*Multi-axis tilt sensor to enable remote monitoring of the pyranometer mounting and orientation. 多軸傾斜感測器可達到對日射強度計安裝和方向的遠端監控
*Internal humidity and temperature monitoring to provide confidence in the integrity of the instruments internal functionality. 內部濕度和溫度監控功能可確保儀器內部功能的完整性
The SMP12 has a 2-wire RS-485 Modbus® RTU interface but, unlike the other SMP models, it does not have an analog output. The characteristics of the thermopile detector provide a fast response time of less than half a second. The wide power supply range from 10 to 30 VDC makes integration into solar energy plant performance monitoring stations easy. SMP12 has class-leading electrical protection in the form of 2-stage surge and reverse polarity protection on the power input and 3-stage surge protection on the RS-485 data lines.
Like all SMP series pyranometers, the calibrated sensitivity is stored in memory and can be accessed via the Modbus® interface and the measured irradiance value is output via Modbus® in W/m². This makes it easy and simple to interchange different instruments when recalibration or repair is required. 和所有 SMP 系列日射強度計一樣，校正後的靈敏度儲存在記憶體中，可透過 Modbus® 介面瀏覽，測量的輻照度值以 W/m² 為單位透過 Modbus® 輸出。在需要重新校正或維修時，即可輕鬆且方便地更換不同的儀器。
SmartExplorer Windows™ software provides: data logging on a PC, displaying of data, changing Modbus® communication settings, configuring of the Modbus® addresses – and more. SmartExplorer is free and can be found under the ‘Downloads’ tab of this webpage.
應用：氣象、太陽光電、科學研究、工業、農業
關鍵字 : Kipp & Zonen 全天候 陽光輻射計, 輻照度計, 日照計, 氣象站 設備, 日照 強度計, 太陽輻射計, 太陽日照計, solar radiation measurement, 日射強度計, 太陽輻射測量儀器
The SMP12 combines proven sensor and diffuser technology from the RaZON+ PH1 and PR1 radiometers with an enhanced version of the Smart interface and the low maintenance of the SMP10. 結合 RaZON+ PH1 和 PR1 輻射計成熟的感測器和擴散器技術，並配備強化版智慧介面，同時保留 SMP10 的低維護量特色。
The SMP12 has an internal drying cartridge that will last for at least 10 years if the housing is unopened. This reduces maintenance significantly. Due to the SMP12's superior non-stability, the instrument needs to be recalibrated every 5-years from the date of installation to remain within its performance parameters. To be compliant with IEC61724-1 Class A system requirements, recalibration is every 2-years from date of installation. SMP12 內建乾燥盒，在未打開外殼的情況下，乾燥盒的使用年限可達 10 年。此明顯降低日常維護量。為保持其性能參數，自安裝之日起需要每 5 年進行重新校正。為符合 IEC61724-1 A 級系統要求，建議自安裝日起每 2 年進行一次重新校正。
The SMP12 feature set includes:
*Solid-state dome heating for dew and frost prevention. 固態穹頂加熱，防止露水和霜凍
*Multi-axis tilt sensor to enable remote monitoring of the pyranometer mounting and orientation. 多軸傾斜感測器可達到對日射強度計安裝和方向的遠端監控
*Internal humidity and temperature monitoring to provide confidence in the integrity of the instruments internal functionality. 內部濕度和溫度監控功能可確保儀器內部功能的完整性
The SMP12 has a 2-wire RS-485 Modbus® RTU interface but, unlike the other SMP models, it does not have an analog output. The characteristics of the thermopile detector provide a fast response time of less than half a second. The wide power supply range from 10 to 30 VDC makes integration into solar energy plant performance monitoring stations easy. SMP12 has class-leading electrical protection in the form of 2-stage surge and reverse polarity protection on the power input and 3-stage surge protection on the RS-485 data lines.
Like all SMP series pyranometers, the calibrated sensitivity is stored in memory and can be accessed via the Modbus® interface and the measured irradiance value is output via Modbus® in W/m². This makes it easy and simple to interchange different instruments when recalibration or repair is required. 和所有 SMP 系列日射強度計一樣，校正後的靈敏度儲存在記憶體中，可透過 Modbus® 介面瀏覽，測量的輻照度值以 W/m² 為單位透過 Modbus® 輸出。在需要重新校正或維修時，即可輕鬆且方便地更換不同的儀器。
SmartExplorer Windows™ software provides: data logging on a PC, displaying of data, changing Modbus® communication settings, configuring of the Modbus® addresses – and more. SmartExplorer is free and can be found under the ‘Downloads’ tab of this webpage.
應用：氣象、太陽光電、科學研究、工業、農業
關鍵字 : Kipp & Zonen 全天候 陽光輻射計, 輻照度計, 日照計, 氣象站 設備, 日照 強度計, 太陽輻射計, 太陽日照計, solar radiation measurement, 日射強度計, 太陽輻射測量儀器
- ISO 9060 spectrally flat fast response Class A and IEC 61724-1 Class A monitoring
- Pioneering Class A integrated dome heating with no moving parts preventing dew & frost
- Enhanced surge protection conforming to EN 61000-6-2 Industrial standard
- remote tilt angle and internal humidity monitoring
- RS-485 Modbus® communication
- 5-year warranty & maximum calibration interval
