水中氯離子電極 Intellical™ ISECL181 Chloride (Cl-) Ion Selective Electrode (ISE), 1m or 3m cable
產品編號：ISECL18101, ISECL18103
Hach ISECL181數位複合式離子選擇性電極(探頭)適用於測量廢污水，飲用水和一般水質之氯離子濃度。
IntelliCALⓇ ISECL181 is a digital, combination, Chloride ion selective electrode (ISE) with a with a non-refillable gel driTEK reference with a double junction, ceramic porous pin and porous PTFE annular ring, and built-in temperature sensor. The electrode measures Chloride concentration in water samples. The laboratory version of this ISE is shockproof with its Epoxy plastic body.The IntelliCAL ISECL181 probe is available with a 1 or 3 meter cable and is intended for laboratory use. The ISECL181’s solid-state sensor design eliminates membrane replacement and allows for dry storage of the ISE. The ISECL181 is ideal for measuring chloride concentrations in wastewater, drinking water and general water quality applications.
配備一次性填充凝膠 driTEK 參考電極、雙液接點、陶瓷多孔針和多孔 PTFE 環形環，內建溫度感測器。實驗室機型採用環氧塑膠外殼，具防震功能。ISECL181 的固態感測器設計無需更換薄膜，ISE 能夠乾燥儲存。
Parameter 分析參數 : Chloride
Method 分析方法 : 10255 Direct Measurement Powder Pillow ISA
Range 量測範圍 : 3.55 - 35 g/L Cl-
Sensor Type : Solid-state crystal membrane
Reference Type : Ag/AgCl
Accuracy : ±0.02 mV or 0.05%, whichever is greater
Resolution : Selectable up to 4 significant digits
Special Features : Dry storage & fast response time. No replacement membranes.
*使用Hach HQ系列主機進行分析
關鍵字 : 水中 氯離子 濃度 分析 探頭, Chloride probe, chloride meter, chloride 水質計, 檢測 水中氯離子 濃度
IntelliCALⓇ ISECL181 is a digital, combination, Chloride ion selective electrode (ISE) with a with a non-refillable gel driTEK reference with a double junction, ceramic porous pin and porous PTFE annular ring, and built-in temperature sensor. The electrode measures Chloride concentration in water samples. The laboratory version of this ISE is shockproof with its Epoxy plastic body.The IntelliCAL ISECL181 probe is available with a 1 or 3 meter cable and is intended for laboratory use. The ISECL181’s solid-state sensor design eliminates membrane replacement and allows for dry storage of the ISE. The ISECL181 is ideal for measuring chloride concentrations in wastewater, drinking water and general water quality applications.
配備一次性填充凝膠 driTEK 參考電極、雙液接點、陶瓷多孔針和多孔 PTFE 環形環，內建溫度感測器。實驗室機型採用環氧塑膠外殼，具防震功能。ISECL181 的固態感測器設計無需更換薄膜，ISE 能夠乾燥儲存。
Parameter 分析參數 : Chloride
Method 分析方法 : 10255 Direct Measurement Powder Pillow ISA
Range 量測範圍 : 3.55 - 35 g/L Cl-
Sensor Type : Solid-state crystal membrane
Reference Type : Ag/AgCl
Accuracy : ±0.02 mV or 0.05%, whichever is greater
Resolution : Selectable up to 4 significant digits
Special Features : Dry storage & fast response time. No replacement membranes.
*使用Hach HQ系列主機進行分析
關鍵字 : 水中 氯離子 濃度 分析 探頭, Chloride probe, chloride meter, chloride 水質計, 檢測 水中氯離子 濃度
Requires virtually no maintenance 幾乎無需維護
The solid-state sensor design allows for DRY storage of the ISE without a shelf life. Also, the probe does not require the electrolyte to be refilled or membrane replacement.
固態感測器設計讓離子選擇性電極（ISE）得以乾式儲存。此外，此探頭無需補充電解液或更換膜片。
The solid-state sensor design allows for DRY storage of the ISE without a shelf life. Also, the probe does not require the electrolyte to be refilled or membrane replacement.
Fast, stable, and accurate results 快速、穩定、準確取得分析結果
Intellical digital probes lock on the result when the measurement is stable, removing the guesswork in having a moving number. Additionally, the probe’s large annular reference junction provides maximum surface area between sample and reference electrolyte for fast measurement stability.
Intellical digital probes lock on the result when the measurement is stable, removing the guesswork in having a moving number. Additionally, the probe’s large annular reference junction provides maximum surface area between sample and reference electrolyte for fast measurement stability.
IntelliCAL 數位探頭在測量穩定後會鎖定結果，避免因數值波動而造成的猜測。
Ultimate traceability in measurement history 測量記錄的可追溯性
Stored time and date stamp for each measurement, operator and sample ID, calibration history, parameter, and probe serial number
Stored time and date stamp for each measurement, operator and sample ID, calibration history, parameter, and probe serial number
儲存每次測量的時間和日期戳記、操作人員和樣品 ID、校正歷史記錄、參數和探頭序號
Can be moved between meters without the need to re-calibrate or re-enter measurement settings 無需重新校正或重新輸入測量設定，即可靈活搭配HQd系列的主機使用。
Ideal for a multi-user environment with multiple HQD series Laboratory and Portable meters
