水中油感測器 (具自清潔功能) FP360 sc Oil-in-Water Sensor, 500 ~ 5000 ppb, titanium body, 10 m cable, with cleaning unit
產品編號：
Hach FP360 sc Oil-in-Water Continuous Online Monitoring Sensor
FP360 sc 測油儀為採用紫外螢光分析法的水中油線上分析儀，靈敏度高。可選配耐腐蝕的鈦合金材質探頭，不受懸浮顆粒物干擾，提供多種安裝方式，可與Hach SC系列控制器連接。UV螢光法連續偵測水中油，高精密度，高靈敏度，高效率，運作穩定
Even the smallest oil traces can impair water quality. The FP 360 sc is specifically designed to detect traces of mineral oils in water while providing the necessary value and benefits for a positive return on investment. The sensor monitors surface water, process water and industrial water continuously. It has a submersible probe design. The sensor comes with an optional cleaning unit. Calibrate once every two years. Available in stainless steel or titanium.
即使是最細微的油跡也會影響水質。 FP 360 sc 水中油感測器專為監測水中的礦物油而設計，可連續監測地面水、工藝用水和工業用水。 浸入式電極設計。 可選配清潔裝置。 每兩年校正一次。 提供不銹鋼或鈦材質。
FP360 oil in water sensor 水中油分析儀檢測溶解性和乳化性的油，鈦合金探頭可用於海水或高含鹽水樣。 多種安裝方式供選擇。
Measurement Method 分析方法 : UV fluorescence method for polycyclic aromatic hydrocarbons (PAH)
Detector 偵測 : UV photodiode with interference filter; Compensation of daylight and flashlamp intensity fluctuations
The FP360 sc can be connected to all SC controllers thus providing versatile output options including 4-20 mA Output, Modbus RS485, Profibus, or Hart. 與Hach SC系列控制器相容
Product Number : LXV441.99.11202
Range 量測範圍 : 0 - 500 ppb (µg/L) (PAH) or 0.1 - 15 ppm (mg/L) (Oil)
Product Number : LXV441.99.21202
Range 量測範圍 : 0 - 5000 ppb (µg/L) (PAH) or 0.1 - 150 ppm (mg/L) (Oil)
Reproducibility : 2.5 % of measured value at constant temperature
Response Time : T90 10 s
Calibration 校正 : Factory calibrated with UV fluorescence standard or process calibration with results of a grab sample analysis.
Controller Compatibility : SC4500, SC1000, SC200 使用 Hach SC系列 digital controllers 數位控制主機進行監控
關鍵字 : oil water 監測, 水中油 連續 監測, 汙水 油脂 偵測, 檢測 污水 油脂, 監測 水中 油脂, 廢水 油脂 分析, 放流水 油脂, 污水 油 分析儀, 水中油分析儀, 水中油監測儀
FP360 sc 測油儀為採用紫外螢光分析法的水中油線上分析儀，靈敏度高。可選配耐腐蝕的鈦合金材質探頭，不受懸浮顆粒物干擾，提供多種安裝方式，可與Hach SC系列控制器連接。UV螢光法連續偵測水中油，高精密度，高靈敏度，高效率，運作穩定
Even the smallest oil traces can impair water quality. The FP 360 sc is specifically designed to detect traces of mineral oils in water while providing the necessary value and benefits for a positive return on investment. The sensor monitors surface water, process water and industrial water continuously. It has a submersible probe design. The sensor comes with an optional cleaning unit. Calibrate once every two years. Available in stainless steel or titanium.
即使是最細微的油跡也會影響水質。 FP 360 sc 水中油感測器專為監測水中的礦物油而設計，可連續監測地面水、工藝用水和工業用水。 浸入式電極設計。 可選配清潔裝置。 每兩年校正一次。 提供不銹鋼或鈦材質。
FP360 oil in water sensor 水中油分析儀檢測溶解性和乳化性的油，鈦合金探頭可用於海水或高含鹽水樣。 多種安裝方式供選擇。
Measurement Method 分析方法 : UV fluorescence method for polycyclic aromatic hydrocarbons (PAH)
Detector 偵測 : UV photodiode with interference filter; Compensation of daylight and flashlamp intensity fluctuations
The FP360 sc can be connected to all SC controllers thus providing versatile output options including 4-20 mA Output, Modbus RS485, Profibus, or Hart. 與Hach SC系列控制器相容
Product Number : LXV441.99.11202
Range 量測範圍 : 0 - 500 ppb (µg/L) (PAH) or 0.1 - 15 ppm (mg/L) (Oil)
Product Number : LXV441.99.21202
Range 量測範圍 : 0 - 5000 ppb (µg/L) (PAH) or 0.1 - 150 ppm (mg/L) (Oil)
Reproducibility : 2.5 % of measured value at constant temperature
Response Time : T90 10 s
Calibration 校正 : Factory calibrated with UV fluorescence standard or process calibration with results of a grab sample analysis.
Controller Compatibility : SC4500, SC1000, SC200 使用 Hach SC系列 digital controllers 數位控制主機進行監控
關鍵字 : oil water 監測, 水中油 連續 監測, 汙水 油脂 偵測, 檢測 污水 油脂, 監測 水中 油脂, 廢水 油脂 分析, 放流水 油脂, 污水 油 分析儀, 水中油分析儀, 水中油監測儀
Lowest Cost of Ownership
The FP 360 sc is specifically designed to detect traces of mineral oils in water while providing the necessary value and benefits for a positive return on investment.
The Right Technology for the Right Price
Due to its unique combination of submersible probe design and UV fluorescence sensing technology, the FP 360 sc delivers the best technology to detect oil in water and is priced below competitive UV fluorescent instruments.
Due to its unique combination of submersible probe design and UV fluorescence sensing technology, the FP 360 sc delivers the best technology to detect oil in water and is priced below competitive UV fluorescent instruments.
Minimal Maintenance
The FP 360 sc has no tubes, pumps, or valves that can foul or require constant maintenance interventions. Maintenance is limited to occasional wiping of the sensor's measurement window, calibration once every two years, and Xenon lamp replacement every four years.
The FP 360 sc has no tubes, pumps, or valves that can foul or require constant maintenance interventions. Maintenance is limited to occasional wiping of the sensor's measurement window, calibration once every two years, and Xenon lamp replacement every four years.
Reduced Laboratory Testing
While laboratory testing is the ultimate method of measuring oil in water, it is a long and complex process that requires special equipment and trained lab personnel. The FP 360 sc provides a cost-effective, continuous online monitoring solution to maintain process control and avoid oil contamination with minimal laboratory testing.
While laboratory testing is the ultimate method of measuring oil in water, it is a long and complex process that requires special equipment and trained lab personnel. The FP 360 sc provides a cost-effective, continuous online monitoring solution to maintain process control and avoid oil contamination with minimal laboratory testing.
High Sensitivity and Selectivity
The FP 360 sc can detect and measure polycyclic aromatic hydrocarbons (PAHs) from 1.2 ppb to up to 5000 ppb (µg/L). This is approximately equivalent to a concentration of mineral oil between 0.1 to 150 ppm (mg/L). Furthermore, the FP 360 sc method of detection makes it impervious to interferences by turbid water or natural organic and biological matter that impact online light scattering, UV absorbance, and VIS fluorescence instruments.
The FP 360 sc can detect and measure polycyclic aromatic hydrocarbons (PAHs) from 1.2 ppb to up to 5000 ppb (µg/L). This is approximately equivalent to a concentration of mineral oil between 0.1 to 150 ppm (mg/L). Furthermore, the FP 360 sc method of detection makes it impervious to interferences by turbid water or natural organic and biological matter that impact online light scattering, UV absorbance, and VIS fluorescence instruments.
Available in stainless steel or titanium housing for measurement in the harshest of conditions
有不銹鋼或鈦外殼材質可選，嚴苛環境條件下之測量
Product Number: LXV441.99.11202 : Range 量測範圍 : 0 - 500 ppb (µg/L) (PAH) or 0.1 - 15 ppm (mg/L) (Oil)
Product Number: LXV441.99.21202 : Range 量測範圍 : 0 - 5000 ppb (µg/L) (PAH) or 0.1 - 150 ppm (mg/L) (Oil)
