水中氟離子分析電極 Intellical™ ISEF121 Fluoride (F⁻) Ion Selective Electrode (ISE), 1 m cable
產品編號：ISEF12101
ISEF121 數位型氟離子選擇電極是測量廢水，飲用水和一般水質應用中氟化物濃度的理想選擇。有1公尺與3公尺長度可選，內建溫度傳感器，此ISE的實驗室版本採用環氧塑料主體，防震。
Intellical™ ISEF121 is a digital, combination, Fluoride ion selective electrode (ISE) with a with a non-refillable gel reference with a single junction porous PTFE annular ring, and built-in temperature sensor. The electrode measures fluoride concentration in water samples. The laboratory version of this ISE is shockproff with its Epoxy plastic body.The Intellical ISEF121 probe is available with a 1 or 3 meter cable and is intended for laboratory use.
The ISEF181’s solid-state sensor design eliminates membrane replacement and allows for dry storage of the ISE. The ISEF121 is ideal for measuring fluoride concentrations in wastewater, drinking water and general water quality applications.
Range : 0.01 mg/L (5 x 10-7 M) - 19 g/L (1 M) F⁻
Accuracy : ±0.02 mV or 0.05%, whichever is greater
Reference Type : Ag/AgCl
Resolution : Selectable up to 4 significant digits
Electrode Type : Non-Refillable Dritek Gel Reference Element
*使用 Hach HQD系列 meter 智慧型數位水質主機進行分析
關鍵字 : 水 氟 濃度 探頭, Fluoride probe, 手持式 氟離子 測定, 氟化物 濃度, 水 氟選擇性電極
Intellical™ ISEF121 is a digital, combination, Fluoride ion selective electrode (ISE) with a with a non-refillable gel reference with a single junction porous PTFE annular ring, and built-in temperature sensor. The electrode measures fluoride concentration in water samples. The laboratory version of this ISE is shockproff with its Epoxy plastic body.The Intellical ISEF121 probe is available with a 1 or 3 meter cable and is intended for laboratory use.
The ISEF181’s solid-state sensor design eliminates membrane replacement and allows for dry storage of the ISE. The ISEF121 is ideal for measuring fluoride concentrations in wastewater, drinking water and general water quality applications.
Range : 0.01 mg/L (5 x 10-7 M) - 19 g/L (1 M) F⁻
Accuracy : ±0.02 mV or 0.05%, whichever is greater
Reference Type : Ag/AgCl
Resolution : Selectable up to 4 significant digits
Electrode Type : Non-Refillable Dritek Gel Reference Element
*使用 Hach HQD系列 meter 智慧型數位水質主機進行分析
關鍵字 : 水 氟 濃度 探頭, Fluoride probe, 手持式 氟離子 測定, 氟化物 濃度, 水 氟選擇性電極
| Fluoride | Method | Range | Reagent Set(s) | USEPA Compliant? |
|---|---|---|---|---|
| 8323 Direct Measurement ISE | 0.01 saturated mg/L F- | View | ||
| 8323 Direct Measurement ISE | 0.02 saturated mg/L 1x10-6 M | |||
| 8323 Direct Measurement ISE | 0.02 - 19,000 mg/L F- | |||
| 8323 ISE Electrode, Direct Measure in Acid Solutions | 0.1 - 100.0 Mg/L F | View | ||
| 8323 ISE Electrode, Direct Measure, Drinking Water, PP or TISAB | 0.1 - 10.0 mg/L F- | View | Y | |
| Electrochemical | 0.1 - 10 mg/L | View |
Requires virtually no maintenance
The solid-state sensor design allows for DRY storage of the ISE without a shelf life. Also, the probe does not require the electrolyte to be refilled or membrane replacement.
Fast, stable, and accurate results
Intellical digital probes lock on the result when the measurement is stable, removing the guesswork in having a moving number. Additionally, the probe’s large annular reference junction provides maximum surface area between sample and reference electrolyte for fast measurement stability.
Ultimate traceability in measurement history
Stored time and date stamp for each measurement, operator and sample ID, calibration history, parameter, and probe serial number
Can be moved between meters without the need to re-calibrate or re-enter measurement settings
Ideal for a multi-user environment with multiple HQD series Laboratory and Portable meters
