The EPA approved TU5 Series® platform employs a unique optical design that sees more of your sample than any other turbidimeter, delivering the best low level precision and sensitivity while minimizing variability between measurements. For the first time you will be able to remove uncertainty of which measurement to trust between your lab and process instruments, thanks to identical 360° x 90° Detection® Technology in any TU5 Series turbidimeter.
Hach TU5系列線上濁度計方法取得美國環保署核准，創新突破的360° x 90° Detection™ 專利光學偵測技術，能偵測到更多的水質濁度狀況，提供最佳的低濃度濁度監測精準度和靈敏度，以及更快速的濁度自動監測。

The TU5300sc Low Range Laser Turbidimeter dramatically reduces the time needed to get a turbidity measurement you can rely on. A stable laser light source eliminates the need for annual lamp replacements. The turbidimeter’s measurement surface area has been reduced by 98%, allowing you to save time cleaning. An automatic cleaning module is available that keeps your instrument clean, reducing the amount of time spent cleaning the instrument ever further. All of this, along with the ability to measure to 2 mNTU, gives you the next standard in the evolution of turbidity.
穩定的雷射光源無需每年更換燈泡。濁度計的測量表面積減少了 98%，因而節省清潔時間。可選配自動清潔模組以保持儀器清潔，進一步減少清潔時間。加上 2 mNTU 的測量能力，為您帶來濁度測量領域的全新標準。

Only the new TU5 Series Lab & Process Turbidimeters with 360° x 90° Detection deliver unprecedented confidence that a change in your reading is a change in your water.
TU5系列濁度監測儀測試快，反應快，節省水量。實驗室設備無需使用矽油擦拭樣品瓶，縮減測試所需的步驟並減少可能的誤差。

Certifications :
CE compliant
US FDA accession number: 1420493-000 EPA version, 1420492-000 ISO version
Australian ACMA Marking

Light Source : Class 2 laser product, with embedded 650 nm (EPA 0.43 mW) or Class 1 laser product, with embedded 850 nm (ISO), max. 0.55 mW (complies with IEC/EN 60825-1 and to 21 CFR 1040.10 in accordance with Laser Notice No. 50)

Stray Light : <10 mNTU

Range 量測範圍
EPA 機款 :
0 - 700 NTU / FNU / TE/F / FTU
0 - 100 mg/L
0 - 175 EBC

ISO 機款 :
0 - 1000 NTU / FNU / TE/F / FTU
0 - 100 mg/L
0 - 250 EBC

Accuracy :
±2% or 0.01 NTU from 0 - 40 NTU
±10% of reading from 40 - 1000 NTU based on Formazin primary standard

Repeatability : Better than 1% of reading or ±0.002 NTU (TU5300sc) or ±0.0006 NTU (TU5400sc) on Formazin at 25 °C (77 °F), whichever is greater

Resolution : 0.0001 NTU / FNU / TE/F / FTU / EBC

Response Time :
TU5300sc: T90 <45 seconds at 100 mL/min
TU5400sc: T90 <30 seconds at 100 mL/min

Sample Flow Rate : 100 - 1000 mL/min; optimal flow rate: 200 - 500 mL/min

Calibration Method 校正方法 :
For Formazin and Stablcal®:
20 NTU from 0 to 40 NTU; at 20 FNU and 600 NTU for full range
Custom calibration for up to 6-point calibrations

Verification :
Liquid: Stablcal®, Formazin (0.1 - 40 NTU)
Dry: Glass Rod at <0.1 NTU
